The CS-Pro VET is the world's smallest and most advanced handheld shockwave device, weighing just 14.5 oz.
​
It is tailored for treating companion animals and addressing complex equine conditions. This noninvasive device uses high-pressure acoustic shock waves to trigger a biological healing response in musculoskeletal and soft tissue, offering an innovative solution for veterinary care.
Key Features
The CS-Pro VET offers several benefits to veterinary clinics, including:
-
Precision: The device offers precise treatment options with supported focal depths, ensuring effective therapy for various conditions.
-
Portability: Its lightweight and battery-powered design allow veterinarians to bring advanced treatment capabilities directly to their patients, whether in the clinic or in the field.
-
Versatility: The CS-Pro VET can be used across a wide range of veterinary applications, from treating injuries to managing chronic pain.
-
Longevity: With a lifespan of over 5,000,000 pulses and up to 100,000 shocks per battery charge, the device provides long-term value and reliability.
Included
-
Hard Carrying Case
-
Waterproof IPX7, Dustproof IPX6, Mil-Spec Certified, Airline Check-in and Carry-on approved
-
CS-Pro VET Handheld Device Focal
-
Focal Standoffs
-
2, 5, 10, 20, 30mm with dust covers
-
Hand Strap
-
Shoulder Strap
-
Li-Ion Batteries (QTY 2)
-
Charger
-
Transducer Couplant Oil
-
User Manual
Specifications:
Device Information
Unit Weight: 14.5 oz
Battery Life: 1000,000 shocks
Product lifespan: > 5 million shocks
Standoffs: 2, 5, 10, 20, & 30mm​
Shock Wave Characteristics
Parameters calculated per IEC 61846​
Energy Flux Density: 0.02 - 0.22 mJ/mm2
Peak Positive Pressure*: 80 MPa
Peak Negative Pressure*: - 12 MPa
Rise Time*: < 15 ns
Pulse Duration*: 100 ns
Pulse Repetition Rate: 2 - 12 HZ
Focus Penetration Depth: 2 - 30 Hz
Therapeutic Volume (5MPa)*: 1000 mm3
Focal Volume (-6dB)*: 10 mm3​​
​
*nominal values displayed
What is Shockwave Therapy?
​
Shockwave therapy, specifically Focused Extracorporeal Shock Wave Therapy (F-ESWT), is a non-invasive treatment method that uses high-pressure acoustic waves to stimulate healing in musculoskeletal and soft tissue conditions. This therapy is evidence-based and has been shown to effectively treat a variety of conditions in both humans and animals by triggering a biological healing response.
How does it work?
​
The CS-Pro VET generates focused acoustic shock waves that are transmitted into the tissue at a specific depth and location, as guided by medical protocol. These waves stimulate healing by enhancing blood circulation, reducing inflammation, and promoting cell regeneration in the affected areas.
Frequently Asked Questions
What does this device help treat?
Companion Animals:
-
Shoulder diseases - Bicipital tenosynovitis, Supraspinatus and Infraspinatus insertional tendinopathy​
-
Elbow diseases - Degenerative joint disease
-
Carpal diseases - Degenerative joint disease, Tendon/Ligament injuries acute and chronic
-
Intervertebral disc disease & Lumbosacral stenosis
-
Coxofemoral diseases - Degenerative joint disease, Iliopsoas trigger points
-
Stifle diseases - Cranial cruciate disease, Patella luxation, Degenerative joint disease, Patella tendonitis, Medial and lateral collateral ligament inflammation, Long digital extensor tendonitis
-
Tarsal diseases - Ligament injuries acute and chronic, Achilles tendinopathy
-
Wounds
-
Osteochondritis dessicans (OCD)
Equine
-
Localization of pain points
-
Myofascial pain syndrome
-
Myogelosis/muscle strain
-
Massage after strain
-
Insertion desmopathy
-
Tendinopathy
-
Sesamoiditis
-
Calcifications
-
Degenerative joint disease
-
Pseudarthrosis
-
Periosteal reaction
What benefits can it bring to your clinic?
Non-Invasive Alternative:
It provides a non-surgical treatment option for patients, which is often appealing to those seeking less invasive solutions.
Improved Patient Outcomes:
Shockwave therapy has been effective in treating various conditions, which can lead to higher patient satisfaction and potentially better treatment outcomes.
Quick Treatment Sessions:
The therapy sessions are typically short, allowing for more patient appointments in a day.
Reduced Need for Medication:
This therapy can decrease the reliance on pain medication, appealing to patients seeking drug-free treatment options.
High Safety Profile:
The treatment is generally safe with minimal side effects, increasing its acceptability among patients.
Return on Investment (ROI):
Despite the initial cost, the device can be a profitable long-term investment due to its wide range of applications and potential to draw in more patients.
Ease of Use:
Many modern shockwave devices are user-friendly, ensuring a smoother integration into the clinic's existing treatment protocols.
Educational and Marketing Support:
Manufacturers often provide comprehensive training and marketing materials, aiding in staff education and promotional activities.
Is it safe to use?
​
Shockwave therapy is considered very safe with no need of sedation. Due to the different focal points, the animal will not feel anything and have very little noise unlike other shockwave device.
